High-speed Two-hammer Rock Driller
Features
Used for vertical drilling in stone quarry , adpot heavy rock drill hammer and driven by compressed air, high working efficiency and easy operation.
Technical Data
技术参数/Technical Parameter | ||
钻孔直径 | Dia-34mm - Dia-42mm | |
Hole Diameter | ||
钻孔深度 | Max.6m | |
Drill depth | ||
单杆钻进速度 | 5-20m/h | |
Single rod drill speed | ||
单次给进行程 | 2m | |
Single advance | ||
耗气量 | 10-12m⒊/min | |
Air consumption | ||
工作压力 | 0.5-0.7Mpa | |
Air pressure | ||
导轨行程 | 1x4m | |
Track travel | ||
给进功率 | 1.5KW | |
Advance power | ||
整机总重量 | 1000KG | |
Total weight |
High-speed Two-hammer Rock Driller Partial display
